GCA · Cleanroom Equipment · 5 models
By Lab Manufacturers China Technical TeamLast reviewed Standards: ISO 14644-1 (cleanroom classification), ISO 14644-5 (cleanroom operations), EU GMP Annex 1 (sterile manufacturing)
Garment cabinets are ventilated or HEPA-filtered storage cabinets that hold cleanroom garments between uses, protecting them from dust and, in some designs, sterilizing them with UV. Pharmaceutical, electronics and biotech gowning rooms use them to keep coveralls, hoods and boots clean.
5 models of Garment Cabinets
The 5 models below are current configurations; specifications are confirmed on quotation.
不锈钢洁净服柜
A stainless steel garment cabinet is a ventilated storage cabinet with hanging rods and louvred or glazed doors. It is the basic solution for storing cleanroom garments in ISO 7–8 gowning areas.
HEPA 通风洁净服柜
A HEPA-ventilated garment cabinet circulates filtered air over stored garments and maintains positive internal pressure. It is used for ISO 6–7 gowning where garments must stay particle-free. It suits ISO 6–7 gowning rooms.
紫外灭菌洁净服柜
A UV sterilizing garment cabinet irradiates stored garments with 254 nm UV-C lamps during timed cycles. It provides supplementary surface disinfection for reusable garments stored between wears. It is a supplementary measure only.
带鞋柜和长凳的洁净服柜
This garment cabinet combines hanging space for coveralls with a shoe compartment and a seat bench. It supports gowning-room layouts where staff change footwear and garments in one station. It suits shared gowning stations.
正压吹扫无菌服储存柜
A sterile garment storage cabinet holds pre-sterilized garments under filtered, positive-pressure air, protecting them from contamination until use. It is used in ISO 5–7 gowning for Grade A and B aseptic areas.
| Model | Material | Width | Depth | Height | Capacity |
|---|---|---|---|---|---|
| Stainless Steel Cleanroom Garment CabinetGCA-0001 | 304 stainless steel | 600 / 900 / 1200 mm | 500–600 mm | 1800–2000 mm | 4–12 coveralls |
| HEPA-Ventilated Garment CabinetGCA-0002 | 304 stainless steel | 900–1800 mm | — | — | 6–16 hangers |
| UV Sterilizing Garment CabinetGCA-0003 | 304 stainless steel | 600–1200 mm | — | — | 3–10 garments |
| Garment Cabinet with Shoe Storage and BenchGCA-0004 | 304 stainless steel | 900–1800 mm | 500–600 mm | 1800–2000 mm | — |
| Sterile Garment Storage Cabinet with Positive Pressure PurgeGCA-0005 | — | 900–1500 mm | — | — | 6–12 sterile garments |
Indicative values for this product class. Final specifications are confirmed on the quotation and in the calibration documents supplied with the instrument.
A garment cabinet provides enclosed storage with controlled airflow so that garments remain dry and particle-free. Basic units have stainless steel or powder-coated steel shelves and hangers with louvred or perforated doors. Ventilated versions draw room air through a prefilter and HEPA filter and circulate it over the garments, keeping positive pressure inside so dust cannot enter. UV-C lamps at 254 nm irradiate hanging garments for surface disinfection, with timers and door switches for safety. Some units include heated drying or nitrogen purge for sterile garments. Doors are glazed for visibility, and interiors are smooth for wipe-down. Units are sized for 1 to 6 persons and supplied as single or multi-door freestanding cabinets.
Choose by the cleanliness of garments to store and the risk of contamination. For general ISO 7–8 areas, a ventilated steel cabinet may suffice; for sterile or ISO 5–6 garments, use HEPA-ventilated or sterile-purged units. Count the garments per shift and choose the number of compartments or hanger positions, noting coverall volume of about 0.05 m3 per garment. Check door type, glazing and locks, as well as whether UV disinfection is helpful. Verify materials, stainless steel 304 for pharma and powder-coated steel for electronics. Confirm dimensions for gowning-room layout, typical widths 600–1800 mm, and the electrical supply.
Garment Cabinets are specified in gowning rooms, pharmaceutical production, electronics cleanrooms, biotech facilities and medical-device manufacturing.
Work with Garment Cabinets is commonly governed by ISO 14644-1 (cleanroom classification), ISO 14644-5 (cleanroom operations), EU GMP Annex 1 (sterile manufacturing), GB 50073 (cleanroom design code), IEST-RP-CC003 (garment system considerations) and IEC 61010-1. Instrument certifications such as CE marking are confirmed per configuration and never assumed.
Place garment cabinets in the gowning vestibule or clean-side change room, away from draughts and wet areas. Clean the exterior and interior with cleanroom-compatible disinfectants at defined intervals, and replace prefilters every 3–6 months. UV lamps lose intensity after about 8000 hours and do not treat shadowed fabric folds, so they supplement and do not replace laundering. Define garment rotation, cleaning and sterilization cycles, and log them. Do not hang wet garments, and avoid storing personal items in the cabinet. Verify that airflow does not raise particles within the gowning room.
A garment cabinet is an enclosed, ventilated or filtered cabinet that stores cleanroom coveralls, hoods and boots between uses. Some versions add UV-C disinfection or HEPA air to keep garments free of particles.
UV-C reduces microbes on exposed fabric surfaces but does not penetrate folds or shaded areas. It supplements laundering and sterilization but does not replace validated garment sterilization.
Capacity is usually 1 to 6 persons, or 6–30 hangers, depending on width. A typical 1200 mm double-door cabinet holds around 10–12 coveralls on hangers.
Wipe surfaces weekly or per the gowning SOP, and deep clean monthly. Replace HEPA prefilters every 3–6 months and record all cleaning for GMP audits.
