Atomic Force Microscope Profilometer for Nanoscale Roughness
纳米尺度粗糙度用原子力显微轮廓仪
- SKU SUP-0005
- Surface Profilometers
- CE (to be confirmed)
- ISO 9001 manufacturing (to be confirmed)
- Laser safety Class 1 or 2 (to be confirmed)
Price on request — FOB / CIF quoted per order
Prices depend on configuration, quantity and destination port.
Key specifications
| Scan range (XY) | Up to 90 × 90 µm |
|---|---|
| Z range | ≈ 10 µm |
| Vertical noise | < 0.05 nm RMS |
| Lateral resolution | ≈ 1–5 nm |
| Imaging modes | Contact, tapping, non-contact |
| Image resolution | Up to 4096 × 4096 px |
By Lab Manufacturers China Technical TeamLast reviewed Standards: ISO 4287, ISO 21920-2, ISO 25178-2
What is the Atomic Force Microscope Profilometer for Nanoscale Roughness?
A scanning probe instrument that measures nanometer-scale topography by sensing forces between a sharp cantilever tip and the surface. It gives sub-nanometer vertical resolution and is used for wafers, thin films, polymers and nanomaterials where optical resolution is insufficient.
What is the Atomic Force Microscope Profilometer for Nanoscale Roughness?
A scanning probe instrument that measures nanometer-scale topography by sensing forces between a sharp cantilever tip and the surface. It gives sub-nanometer vertical resolution and is used for wafers, thin films, polymers and nanomaterials where optical resolution is insufficient.
Overview
An atomic force microscope uses a cantilever with a tip radius of about 2 to 10 nm, whose deflection is detected by reflecting a laser from its back onto a four-quadrant photodiode. Piezoelectric scanners move the sample or tip over areas from 100 nm to about 100 µm square, with a feedback loop holding deflection or oscillation amplitude constant in contact or tapping mode. The recorded height map has vertical resolution below 0.1 nm and lateral resolution of a few nanometers, allowing Ra and Rq values from ultra-smooth surfaces below 0.2 nm. Scan speeds are slow, typically a few minutes per image, and Z range is limited to about 5 to 15 µm. Tip wear, thermal drift and vibration are primary sources of error.
How does it work?
A stylus profilometer drags a diamond tip, usually with a 2 µm or 5 µm radius, across the surface at a constant speed under a small force, and a transducer converts its vertical displacement to an electrical signal. The raw profile is filtered with a Gaussian filter into roughness and waviness using a cut-off wavelength such as 0.8 mm, and parameters such as Ra, Rz and Rq are calculated according to ISO 4287. Optical profilers use white-light interferometry, confocal microscopy or focus variation to determine height at each pixel by analyzing fringe contrast or sharpness while scanning vertically. They produce areal maps with parameters defined in ISO 25178, such as Sa and Sq, without touching the sample.
What are the key features?
- Contact, tapping and non-contact imaging modes
- Closed-loop piezo scanner with nanometer positioning
- Laser deflection detection with low-noise photodiode
- Sample sizes up to 100 mm wafers with motorized stage
- Active vibration isolation and acoustic enclosure
- Roughness, grain and step analysis software
What are the technical specifications?
A typical atomic force microscope profilometer for nanoscale roughness configuration offers scan range (XY) of Up to 90 × 90 µm, Z range of ≈ 10 µm, vertical noise of < 0.05 nm RMS, lateral resolution of ≈ 1–5 nm, imaging modes of Contact, tapping, non-contact and image resolution of Up to 4096 × 4096 px. Values are indicative of the product class; the exact figures for each configuration are confirmed on the quotation and the calibration documents supplied with the instrument.
Which applications is it used for?
The Atomic Force Microscope Profilometer for Nanoscale Roughness is used in wafer and substrate nanoroughness, thin film and polymer morphology, nanomaterial and graphene imaging and optical coating defects. Across the wider Surface Profilometers class, laboratories also deploy it for machined part surface finish, semiconductor film step height and optical component roughness.
Which standards and certifications apply?
Relevant standards and methods include ISO 4287, ISO 21920-2, ISO 25178-2, ISO 4288 and ASTM D7127. Certification candidates for this model are CE, ISO 9001 manufacturing and Laser safety Class 1 or 2; each is to be confirmed for the specific configuration before shipment, and certificates are supplied only where they have been issued.
Place the instrument on a vibration isolation table or heavy bench and away from drafts, since nanometer-level signals are easily disturbed. Calibrate vertical and horizontal scales with certified step-height or roughness standards at defined intervals, and check stylus wear or tip radius regularly. Clean samples before measurement and mount them level. Specify cut-off length, evaluation length and filter type in the method, because Ra depends on them. Keep stylus force low for soft materials and inspect for scratches. Optical systems need objective cleaning and periodic lateral calibration with grid standards.
How do I select the right Atomic Force Microscope Profilometer for Nanoscale Roughness?
Select this variant when roughness or morphology at the nanometer scale is required, for example on wafers, thin films or nanomaterials. It is slow for large areas and unsuited to rough machined parts. In an RFQ, specify scan range, modes, sample size, isolation and probe supply.
How does it compare with other Surface Profilometers variants?
The main choice is between contact and non-contact. Stylus instruments are traceable, tolerant of steep flanks and dirt, and are the reference for ISO 4287 roughness on machined parts, but they can scratch soft surfaces and cannot reach features smaller than the tip radius. Optical profilers map areas quickly, suit delicate coatings, MEMS and films, and give 3D parameters, but struggle with transparent, very steep or highly reflective or absorbing surfaces. Consider vertical range and resolution, lateral resolution, scan length, sample size and weight, vibration isolation, software filters, and whether the work follows ISO 21920, ISO 25178 or ASTM D7127. Portable roughness testers suit shop-floor checks.
Full specifications
| Scan range (XY) | Up to 90 × 90 µm |
|---|---|
| Z range | ≈ 10 µm |
| Vertical noise | < 0.05 nm RMS |
| Lateral resolution | ≈ 1–5 nm |
| Imaging modes | Contact, tapping, non-contact |
| Image resolution | Up to 4096 × 4096 px |
| Sample size | Up to 100 mm diameter, 20 mm thick |
| Scan speed | 0.1–30 Hz line rate |
| Tip radius | 2–10 nm typical |
| Isolation | Active table and acoustic hood |
Indicative values for this product class. Final specifications are confirmed on the quotation and in the calibration documents supplied with the instrument.
Applications
- Wafer and substrate nanoroughness
- Thin film and polymer morphology
- Nanomaterial and graphene imaging
- Optical coating defects
Key features
- Contact, tapping and non-contact imaging modes
- Closed-loop piezo scanner with nanometer positioning
- Laser deflection detection with low-noise photodiode
- Sample sizes up to 100 mm wafers with motorized stage
- Active vibration isolation and acoustic enclosure
- Roughness, grain and step analysis software
Frequently asked questions about Atomic Force Microscope Profilometer for Nanoscale Roughness
Use AFM when lateral features are below the optical resolution of about 0.3 µm or vertical roughness is below about 0.3 nm. Optical profilers are faster for larger areas and are sufficient for most engineered surfaces.
A 512 × 512 pixel image usually takes 3 to 15 minutes, depending on line rate and scan size. Fast scanning heads reduce this, but resolution and tip-sample force control may be compromised.
Yes. A blunted tip convolves with the surface, underestimating roughness and widening features. Replace probes at defined intervals and check against a reference grating or roughness standard before critical work.
A stylus profilometer physically traces a line with a diamond tip and gives traceable 2D profiles, while an optical profilometer maps an area without contact using interferometry or confocal techniques. Stylus suits machined parts, optical suits delicate or areal analyses.
Ra is the arithmetic mean of absolute profile height deviations from the mean line within the evaluation length, given in micrometers. It is the most common roughness parameter but does not distinguish peaks from valleys, so Rz or Rq may also be reported.
A stylus or optical profiler scans across the edge of a film or etched feature, and the height difference between two levelled reference regions gives the step height. Calibration uses certified step standards, typically from 10 nm to several micrometers.
