Glass Bubble Column Bioreactor

What is the Glass Bubble Column Bioreactor?

A glass bubble column bioreactor aerates and mixes the culture with gas bubbles rising through a simple transparent column. It offers gentle, uniform mixing with no internal parts and is easy to observe.

Overview

A glass bubble column bioreactor consists of a transparent vertical column with a sparger at the base and no draft tube or impeller. Gas bubbles rise through the whole cross-section, transferring oxygen and lifting liquid, so mixing and aeration are achieved with the simplest possible internals. This reduces shear and cleaning complexity, and the transparent wall allows close observation of bubble size, foam and biomass. The design suits relatively low-viscosity cultures and organisms that tolerate bubble contact, such as algae and some yeasts and bacteria. Temperature control is by a jacket or bath, and pH and dissolved oxygen follow the same control principles as other vessels. Height, gas flow and liquid properties determine oxygen transfer, and because there is no mechanical mixing, very viscous broths are difficult to handle.

How does it work?

A glass bioreactor uses a transparent vessel so that mixing, foam, color and biomass can be observed directly during culture. Borosilicate glass resists thermal shock and most cleaning agents, and a detachable headplate carries the agitator, sparger, probes and ports. Temperature is controlled by a water jacket, a heating blanket or a water bath, pH is adjusted by dosing acid, base or carbon dioxide, and dissolved oxygen is held by adjusting gas flow, oxygen fraction or agitation speed. Mixing may be by impeller, by gas-driven circulation in airlift or bubble column designs, or by gentle rocking for sensitive cells. Glass vessels are usually sterilized in an autoclave, which limits their practical size, but they allow rapid changes of impeller, sparger and sensor configuration between experiments.

What are the key features?

• Simple transparent column with base sparger
• No internal draft tube or impeller
• Gentle uniform mixing with low shear
• Direct observation of bubbles and biomass
• Easy assembly and cleaning

What are the technical specifications?

A typical glass bubble column bioreactor configuration offers working volume of 0.5–20 L, column type of Simple bubble column, aeration rate of 0.5–3 vvm, temperature range of Ambient +5 to 60 °C, pH control of 2–12, ±0.05 and dissolved oxygen control of Via gas flow or enrichment. Values are indicative of the product class; the exact figures for each configuration are confirmed on the quotation and the calibration documents supplied with the instrument.

Which applications is it used for?

The Glass Bubble Column Bioreactor is used in algae and cyanobacteria culture, yeast and bacterial studies, low-viscosity fermentation and teaching and demonstration. Across the wider Glass Bioreactors class, laboratories also deploy it for process development and scale-down models, cell culture optimization and microbial fermentation studies.

Which standards and certifications apply?

Relevant standards and methods include ISO 9001, USP <87>, USP <88>, IEC 61010-1, ISO 11133 and GB/T 150. Certification candidates for this model are CE, ISO 9001 manufacturing and IEC 61010-1 compliance; each is to be confirmed for the specific configuration before shipment, and certificates are supplied only where they have been issued.

Inspect glass for chips or cracks before each run, because even a small flaw can fail under autoclaving or pressure. Assemble the headplate carefully so that probes do not touch the impeller, and check that all ports are sealed. Calibrate pH and dissolved oxygen probes before sterilization and confirm they survive the cycle. Use a protective shield or cabinet where pressure or a fragile vessel could present a hazard. Clean glass promptly to avoid baked-on residue, and avoid strong alkalis that etch the surface over time. Replace gaskets and O-rings on a schedule, and keep a log of sterilization cycles for each vessel and headplate.

How do I select the right Glass Bubble Column Bioreactor?

Choose a bubble column for simple, gentle aeration of low-viscosity cultures. In an RFQ specify the volume, the column height, the sparger type, aeration range, temperature control and the instrumentation needed for pH and dissolved oxygen.

How does it compare with other Glass Bioreactors variants?

Choose a glass bioreactor when you need to see the culture, change configuration quickly or work at small volumes. Select the mixing principle from the cell type and oxygen demand: stirred designs give flexible power input, airlift and bubble columns suit shear-sensitive cultures, packed-bed designs suit adherent cells on carriers, and photobioreactors suit photosynthetic organisms. Confirm the working volume and headspace, the number and type of ports, and whether the headplate can accommodate the probes and feeds you need. Check the temperature control method, since a water jacket gives more uniform heating than a blanket, and confirm how the vessel is sterilized. Verify that materials and connectors suit autoclaving and that spare headplates and vessels allow parallel or rapid sequential experiments.
