Reverse Osmosis System with Storage Tank

What is the Reverse Osmosis System with Storage Tank?

A reverse osmosis system with a storage tank buffers demand and provides water on tap from a larger reservoir. It is used where consumption varies widely and a steady continuous capacity is important.

Overview

This system pairs a reverse osmosis unit with a storage tank of 20 to 200 liters, often with a level sensor that starts and stops the pump as the tank fills and empties. The tank lets the membrane run at its efficient design rate in batches rather than following instantaneous demand, which improves recovery and extends membrane life. A distribution pump and pressure vessel deliver water to taps, and the tank may be vented, protected from light and fitted with a UV lamp or air filter to control microbial growth. Conductivity is monitored on the permeate, and low-level and high-level switches protect the pump. Tanked systems are used where several labs or instruments draw water intermittently, and they can supply a downstream deionizer or ultrapure polisher. Sanitization of the tank is a regular maintenance item.

How does it work?

Reverse osmosis applies pressure greater than the osmotic pressure of the feed water to force water through a semipermeable membrane. The membrane rejects most dissolved ions, large organic molecules, colloids, bacteria and particles, while water passes through. Feed is split into permeate, which is the purified product, and concentrate, which carries the rejected contaminants to drain. Recovery, the ratio of permeate to feed, typically ranges from 15 to 50 percent for laboratory units and higher for staged industrial designs. Prefilters remove sediment and chlorine because chlorine attacks polyamide membranes, and a pump supplies the required pressure of 4 to 15 bar depending on feed salinity and membrane type. Monitoring includes pressure, flow, conductivity of permeate and feed, and sometimes temperature correction, because permeate quality falls as temperature drops.

What are the key features?

• Storage tank of 20–200 L with level control
• Pump cycles on tank level to match demand
• Distribution pump and pressure vessel
• Optional UV lamp or air filter on the tank
• Conductivity monitoring on permeate
• Feeds downstream deionizer or polisher

What are the technical specifications?

A typical reverse osmosis system with storage tank configuration offers permeate flow of 10–100 L/h, storage tank of 20–200 L, ion rejection of 95–99 %, level control of Low and high switches, distribution pump of 0.1–0.5 kW and tank protection of Vent, light-shield, optional UV. Values are indicative of the product class; the exact figures for each configuration are confirmed on the quotation and the calibration documents supplied with the instrument.

Which applications is it used for?

The Reverse Osmosis System with Storage Tank is used in laboratories with variable demand, multi-user water supply, feed to ultrapure polishing, washing and rinsing stations and emergency water reserve. Across the wider RO Systems class, laboratories also deploy it for type III water for glassware rinsing, feed water for deionizers and ultrapure systems and reagent and buffer preparation.

Which standards and certifications apply?

Relevant standards and methods include ISO 3696, CLSI GP40, IEC 61010-1, IEC 61326-1 and ISO 9001. Certification candidates for this model are CE, RoHS and ISO 9001 manufacturing; each is to be confirmed for the specific configuration before shipment, and certificates are supplied only where they have been issued.

Protect the membrane by removing chlorine with carbon and softening hard feed to prevent scaling. Run the system regularly rather than leaving it idle, since stagnant water encourages biofilm, and use automatic flush cycles. Sanitize on the schedule recommended for your application, and replace prefilters before pressure drop becomes excessive. Measure permeate conductivity and flow to detect membrane fouling or degradation early. Keep feed water within the specified temperature range, because cold water reduces output and very warm water shortens membrane life. Follow IEC 61010-1 and local plumbing rules, and ensure the drain can carry the concentrate. Record conductivity, recovery and service dates so performance trends are visible.

How do I select the right Reverse Osmosis System with Storage Tank?

Choose a tanked system when demand fluctuates and you want the membrane to run at a steady, efficient rate, or when a reserve is valuable. For constant small draw, a direct-flow unit may suffice. In the RFQ, state tank size, peak demand, purity and sanitization requirements.

How does it compare with other RO Systems variants?

Begin with the feed water analysis: hardness, chlorine, iron, silica, turbidity and conductivity determine the pretreatment and the membrane type. Then size the system by daily and peak permeate volume, remembering that temperature and feed quality affect output. Choose a benchtop or wall-mounted unit for a few liters per hour, and a larger or staged system for higher demand. Check whether you need a storage tank and a distribution pump, and whether the permeate will feed a deionizer or ultrapure unit. Confirm the recovery rate and concentrate handling, since water use and drain capacity matter. Look for conductivity monitoring and automatic flushing, and ask about membrane life, filter change intervals and consumable cost per liter, which usually dominates the total cost.
